Description
SPECIFICATIONS
OPTICAL
Light Source: 512 LEDs (256 RGB / 256 WW) SMD 5050, 50,000 hours life expectancy
Color Temperature (range): 2800 to 8000 K
Color Temperature (at full): 9670 K
CRI: 91.9 @ 4000 K
Beam Angle: 360°
Field Angle: 360°
Illuminance (total): 5 lux @ 5 m – 3 hr run time
Lumens – Output : 1,718 lm – 3 hr run time
PWM Frequency: Scrambled PWM
DYNAMIC EFFECTS
Dimmer: Electronic
Shutter/Strobe: Electronic
Strobe Rate: 0 to 28 Hz
Standalone Color Mixing: Yes
Color Temperature Presets: Yes
Dim Modes: 4
Built-in Automated Programs: Yes
CONSTRUCTION / PHYSICAL
Dimensions: 59.09 x 2.75 x 2.75 in (1501 x 70 x 70 mm)
Dimensions (charging case): 69.8 x 19.5 x 6.4 in 1773 x 495 x 163 mm)
Weight: 9 lb (4.1 kg)
Exterior Color: Black
Housing Material: Aluminum alloy, Plastic
CONNECTIONS
Power Connection (single charger): Edison (Local) plug to Seetronic Powerkon IP65
Power Connection (charging case): Edison (Local) plug to Seetronic Powerkon IP65
Power Input (single charger): Seetronic Powerkon IP65
Power Input (charging case): Seetronic Powerkon IP65
Power Output (charging case): Seetronic Powerkon IP65
Cable Length power (single charger): 5 ft (1.5 m)
Cable Length power (charging case): 5 ft (1.5 m)
CONTROL
Control Protocol: W-DMX
DMX Channels: 4, 15, 64 or 67
Modes/Personalities: 4 personalities
ELECTRICAL
Input Voltage (charging case): 100 to 240 VAC, 50/60 Hz (auto-ranging)
Input Voltage (single charger): 24 VDC, 2.5 A, 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking (charging case): 8 units @ 100 V; 10 units @ 120 V; 10 units @ 208 V; 11 units @ 230 V; 12 units @ 230 V
Power and Current (single charger): 41 W, 0.403 A @ 100 V, 60 Hz
Power and Current (charging case): 164 W, 1.612A @ 100 V, 60 Hz
Power and Current (single charger): 40 W, 0.331 A @ 120 V, 60 Hz
Power and Current (charging case): 160 W, 1.324 A @ 120 V, 60 Hz
Power and Current (single charger): 66 W, 0.315 A @ 208 V, 60 Hz
Power and Current (charging case): 264 W, 1.260 A @ 208V, 60 Hz
Power and Current (single charger): 67 W, 0.291 A @ 230 V, 50 Hz
Power and Current (charging case): 268 W, 1.188 A @ 230 V, 50 Hz
Power and Current (single charger): 67 W, 0.281 A @ 240 V, 50 Hz
Power and Current (charging case): 268 W, 1.124 A @ 240 V, 50 Hz
Power and Current (resting w/single charger): 3 W, 0.035 A @ 100 V, 60 Hz
Power and Current (resting w/charging case): 12 W, 0.140 A @ 100 V, 60 Hz
Power and Current (resting w/single charger): 4 W, 0.036 A @ 120 V, 60 Hz
Power and Current (resting w/charging case): 16 W, 0.144 A @ 120 V, 60 Hz
Power and Current (resting w/single charger): 9 W, 0.043 A @ 208 V, 60 Hz
Power and Current (resting w/charging case): 36 W, 0.172 A @ 208 V, 60 Hz
Power and Current (resting w/single charger): 9 W, 0.041 A @ 230 V, 50 Hz
Power and Current (resting w/charging case): 36 W, 0.164 A @ 230 V, 50 Hz
Power and Current (resting w/single charger): 10 W, 0.042 A @ 240 V, 50 Hz
Power and Current (resting w/charging case): 40 W, 0.168 A @ 240 V, 50 Hz
BATTERY
Battery type: Lithium Ion
Quantity of cells: 5 cells
Rechargeable: Yes
Watt Hours: 185.9 Wh
Battery Charge Time: 4 hours
Battery Life: 3,5,8,12 hours
Battery Power: 18.5 V, 10.05 Ah
CERTIFICATIONS / QUALIFICATIONS
CE, FCC
IP Rating: IP65, for temporary outdoor use
Temperature (startup): -4 °F to 113 °F (-20 °C to 45 °C)
Temperature (operating): -22 °F to 113 °F (-30 °C to 45 °C)
WHAT’S INCLUDED
(4) WELL STX 360
True 1 style power cord with Edison plug (EU bare end)
Charging flight case
(4) tripod stands
(4) hanging eye bolts
(1) IR Remote
Quick Reference Guide
