Description
Frequency Range (+/-3 dB)
80 Hz – 18 kHz
Nominal Directivity (-6 dB) H x V
100° x 12.5°
Maximum Peak SPL**
138 dB
Components LF
2x ND7-LM16 7” Kevlar® Neodymium Driver
Components HF
Adamson NH3 3” Diaphragm / 1.4” Exit Compression Driver
Rigging
Slidelock Rigging System
Connection
Power: powerCON TRUE1 Network: 2x etherCON Analog: 2x XLR
Height Front (mm / in)
203 / 8
Height Back (mm / in)
122 / 4.8
Width (mm / in)
527 / 20.75
Depth (mm / in)
411 / 16.2
Weight (kg / lbs)
17.5 / 38.6
Amplification
2 channel Class-D, 2400 W total output
Input Voltage
100 – 240 V
Current Draw at 230 V
0.45 A rms idle, 1.6 A rms long-term, 9 A max peak
Supported Processing
Onboard / Proprietary
